10GBASE-ZR SFP+ 1550nm 120km Optical 1.25g SFP ZX Transceiver Module
Specifications
| Brand Name | OEM |
| Model Number | sfp module 1.25g |
| Product name | SFP Transceiver |
| Application | Telecommunication |
| Type | Singlemode |
| Certification | ISO9001 |
| Wavelength | 1550nm |
| Fiber Type | dual Fiber Single Mode |
| connector | LC, rj45 |
| Transmission distance | 120km |
| warranty | 3year |
| Working temperature | 0°C ~ +70°C |
Product Application
The 1.25G SFP optical communication module launched by Sintai Communication, Co. , Ltd. has a wide range of products, supports a variety of scenes, including:dual fiber bidirectional transmission, single fiber bidirectional transmission, CWDM and DWDM; The module conforms to the MSA protocol, and it has the characteristics of low power consumption, small size, multi-rate and compatibility with network applications such as Ethernet/SDH/SONET/CPRI/FC, with the farthest transmission distance of up to 120 km; conforms to the RoHS standard and supports digital diagnostic capabilities.
| Model | Description | Transmission distance | Working wavelength | Transmitted optical power | Receiving sensitivity | Overload optical power |
| (km) | (nm) | (dBm) | (dBm) | (dBm) |
| ST-SSGU-55 | SFP, single-mode, 1.25G, dual fiber | 120 | 1550 | 0~5 | ≤-31 | -9 |
Main Features
Adopt SFP hot plug packaging, with LC interface
Support an overall rate of 1. 25G b/s, backward compatiblity
Support optional specifications of double fiber, single fiber, CWDM, DWDM
Suitable for networks such as Ethernet/, FC/, SDH/SONET/CPRI
Single-mode optical fiber supports a transmission distance of up to 120km
Built-in DDM (digital diagnostic monitoring function)
Working temperature: 0°C ~ +70°C
Comply with RoHS standards
